Product Keywords:
Application: machining, cleaning machine, oiling, spraying, etc
Filtration efficiency: ≥99%
Filtration principle: mechanical filtration
Maintenance period: 2000-4000 hours
Maintenance method: clean or replace the filter material
Cleaning method: neutral cleaning solution or weak alkaline cleaning solution soaked in warm water
Installation: Top or side installation of the device
Optional accessories: HEPA high efficiency filter
Maximum air volume: 2200 m³/h
Capture object: oily, water-soluble mist gas exhaust gas temperature: <100℃
Product principle:
Using centrifugal and efficient filtration technology, the oil mist exhaust gas is sucked into the collector under the negative pressure of the fan, and after being homogenized by the air homogenizer, it enters the first stage of coarse effect filtration device, removing large particles of oil mist and impurities above 20um, and then enters the centrifugal separation system, generating strong centrifugal force under the action of the high-speed rotating impeller. The oil mist particles above 3um are separated from the exhaust gas and return to the oil accumulation pan, and finally enter the high efficiency filter to filter out the 0.3um oil mist small particles.
|
Equipment model
|
MP-500-II
|
MP-800-II
|
MP-1500-II
|
MP-2200-II
|
|
Treated air volume(m³/h)
|
500
|
800
|
1500
|
2200
|
|
Power(KW)
|
0.37
|
0.75
|
1.5
|
2.2
|
Wind pressure(Pa)
|
1210
|
1220
|
1350
|
1290
|
Wind pressure(A)
|
1.0
|
1.8
|
3.4
|
4.6
|
Suction diameter A(mm)
|
100
|
120
|
160
|
200
|
Vibration intensity(mm/s)
|
0.02
|
0.03
|
0.04
|
0.05
|
Weight(Kg)
|
35
|
46
|
69
|
79
|
Power source
|
Three-phase 380V/220V/50Hz
|
Rotational speed(R/min)
|
2800
|
|
Noise(dB)
|
≤70
|
Maximum suction temperature (℃)
|
100
|
Purification efficiency
|
99%
|
|
Equipment size(L*W*H)mm
|
840*370*630
|
895*410*680
|
950*520*785
|
1080*560*805
|
Foot hole size(B*C)
|
285*230
|
310*280
|
430*410
|
470*410
|
