Exhaust gas temperature: <100
Product principle:
Using centrifugal and high-efficiency filtration technology, the oil mist exhaust gas is sucked into the collector under the negative pressure of the fan, and after being homogenized by the air homogenizer, it enters the first stage of coarse effect filtration device, removing large particles of oil mist and impurities above 20 μm, and then enters the centrifugal separation system, generating strong centrifugal force under the action of the high-speed rotating impeller. The oil mist particles above 3μm are separated from the waste gas and return to the oil collection pan, and finally enter the high efficiency filter to filter out the 0.3μm oil mist small particles.
Product parameters:
|
Equipment model |
MLP-500 | MLP-1200 |
|
Treated air volume(m³/h) |
800 | 1200 |
|
Power(KW) |
0.25 | 0.55 |
|
Wind pressure(Pa) |
800 | 1100 |
|
Electric current(A) |
0.4 | 1.0 |
|
Suction diameter A(mm) |
120 | 150 |
|
Suction diameter A(mm) |
0.02 | 0.03 |
|
Weight(Kg) |
15 | 30 |
|
Power source |
Three-phase 380V/220V/50Hz |
|
|
Rotational speed(R/min) |
2800 |
|
|
Noise(dB) |
≤70 |
|
|
Maximum suction temperature (℃) |
70 | |
|
Purification efficiency |
99% |
|
|
Equipment size(L*W*H)mm |
398*1000 | 490*1000 |
